A new 3D force platform and calibration method
This work introduces a novel 3D force platform design grounded on the use of planar uniaxial load cells and ball wheels, easy to manufacture from off-the-self components leading to an affordable and accurate system. An accompanying open-sourced software allows an easy use of the force platforms.
A novel calibration method for 3D force platforms is proposed, whose setup uses a Smith-type bodybuilding machine, a triaxial load cell and a pole, allowing in-situ calibration and the application of multidirectional loads, including those exceeding body weight. The calibration matrix is obtained by applying least squares and cross-validation methodology.
Software development and calibration of a force platform for Sports Science
Institutional repository (available soon)
Author's master's thesis in industrial engineering at the University of Almería
This work aims to develop the data acquisition software and calibration procedure of a new triaxial force platform, based on uniaxial load cells with force decoupling between them, ensuring an accurate reading of the normal load to each cell.
The software allows synchronized recording of signals from the force platform, along with other sensors used in biomechanical analysis such as encoders, inertial sensors, and cameras. Additionally, it offers a set of tools available to researchers and Sports Science professionals to visualize and analyze data directly from the software.
Utility Model - Triaxial force platform based on uniaxial load cells
Utility Model number ES1312312, requested by the universities of Almería and Seville.
Inventors
- Javier López Martínez
- Aarón Raúl Poyatos Bakker
- Silvia Sánchez Salinas
- José Luis Blanco Claraco
- José María Muyor Rodríguez
- Daniel García Vallejo
